540XL CONDUCTOR SPECIAL
The Shocker 540 features the insanely loud, American-made, Shocker Horns. These horns are ridiculously loud and, more importantly, actually sound like a train!This air system was designed from the ground up to work amazingly with train horns and it does just that. The Viair 400C can refill the 5 gallon tank from 110 to 150 PSI in just 1 minute and 45 seconds. The air system features everything you'll need to have an extremely loud train horn kit up and running in no time; including, a weatherproof pressure switch with built in relay, all the fittings and air line you'll need, and of course the wire and terminals to get it all hooked up. This complete train horn kit is ridiculously loud.
WHATS IN THE KIT?
- Shocker XL Train Horns - Extremely Durable & Loud
- 5 Gallon 8 Port Air Tank - Industrial Grade Stainless Steel Diaphragms
- Viair 400c Air Compressor - Extra Large 5 Gallon Air Tank
- 110/150 PSI Pressure Switch - Heavy Duty Viair 400c Air Compressor
- 10 Feet of 5/16" Airline - All Inclusive Train Air Horn Solution
- 17 Feet of 1/2" Airline - All Standard Mounting Hardware
- 18 Feet of 10ga Wire - Max Honk Time: 10 to 14 seconds
- 18 Feet of 18ga Wire - Can Be Heard From 2 Miles Away!
- Fittings Kit
- Wiring Terminal Kit
- Detailed Instructions
Specifications:
Shocker 4 Train Horns
- Length: B4 12.75 in (323.85 mm), B3 14.75 in (374.65 mm), B2 16.25 in (412.75 mm), B1 19.5 in (495.3 mm)
- Flare: 5 in (127 mm)
- Weight: 4.5 lbs (2.04 Kg)
- Fitting Size: 1/8in Male NPT
5 Gallon 8 Port Tank
- Length: 20.5 in (520.7 mm)
- Diameter: 9.5 in (241.3 mm)
- Height: 11.5 in (292.1 mm)
- Weight: 20 lbs (9.07 Kg)
Viair 400C Compressor
- Voltage: 12 volts
- Average Refill Time: 1 min 30 sec
- Max Amperage: 26 amps
- Max Duty Cycle: 33% @ 100 PSI
- Max Working Pressure: 150 PSI
- Length: 9 in (228.6 mm)
- Width: 4 in (101.6 mm)
- Height: 7 in (177.8 mm)
- Weight: 8 lbs (3.63 Kg)
